1:24 scale model of Joined Assault Bridge (JAB) on M1 Chassis

Photographing: Creative Photography By Maya exclusively for Gamla Model Makers



This model represents Joint Assault Bridge (JAB) system mounted on M1 tank chassis. In general it is almost identical to its bigger sister, the 1:16 scale JAB model, except it is 66% size and it's diorama base is slightly different.
Like the 1:16 scale JAB model this one is also fully operational, demonstrating a full cycle of the bridge deployment very close to reality. For the purpose of demonstrating the bridge deployment the model is mounted on a diorama type base with a "ravine" filled with concrete anti-tank obstacles.
To create this model we used the same digital tooling that was generated for the 1:16 scale JAB model, only the parts were rapid prototyped 66% of the original size.
The model is packed in a heavy duty military grade plastic cast transit case with a custom foam lining.
